Drifter
The No. 22 Drifter
Starting with the NAHBS-winning Broken Arrow as its foundation, the Drifter is a bike designed for riders needing a capable bike on any road. With generous clearance for up to 45mm tires front and rear (or 50mm on 650B wheels), disc brakes with standard thru-axles and any-road capable geometry, the Drifter is the most versatile bike in our lineup. Compared to the Broken Arrow cyclocross bike, the Drifter has a lower bottom bracket for improved road and gravel handling, along with a slightly longer wheelbase and quicker steering up front. The result is a bike with stable, balanced handling through high speed gravel corners, but with quick enough responses to be ridden aggressively on-road
The Welds are impossibly clean.
"I stared at the headtube for a full 10 minutes trying to find even a hint of a bad weld, a tiny deviation in the bead, an ugly lump or some discoloration. … The ride quality is outstanding. Paired with the 35mm Schwalbe tires, I felt like I was floating over all but the gnarliest terrain. … It’s a rolling statement of taste. I was stopped at least once every ride by someone who wanted to admire the frame."
Bloomberg Pursuits, May 2017
Optional Finishes
Make your No. 22 truly yours. In addition to our standard raw finish, every No. 22 is available in ten optional anodized finishes. Our unique anodizing process gives us the widest range of anodized titanium colours available.
Feature Rich
The Drifter includes as standard what most builders charge extra for. Every Drifter includes:
- Fully butted tubeset, butted in-house by CNC
- 44mm oversized head tube for tapered carbon forks
- Brushed and blasted frame graphics, with no decals or stickers
- Ten year warranty against manufacturing defects
- T47 threaded oversized bottom bracket shell
- Full carbon No. 22 fork designed specifically for our frames
- Generous clearance for 700x45mm or 650x50mm tires
- Thru axles front and rear
Details Matter
Complete your Drifter build with a range of thoughtful finishing details, including:
- Titanium bottle cages finished to match
- No. 22 aluminum stem, custom painted to match the fork
- Our made in house titanium seatpost, finished to match your frame
Specifications
| Brake Type | Flat mount disc brakes |
| Tire Clearance | 45mm/700C or 50mmx650B measured tire |
| Front Axle Spacing | 100x12mm thru-axle |
| Rear Axle Spacing | 142x12mm thru-axle |
| Fork Dimensions | 50mm offset, 382mm length |
| Derailleur Hanger | Syntace X-12 replaceable hanger |
| Bottom Bracket Shell | T47 threaded, 86mm wide |
| Front Derailleur Clamp Size | 34.9mm |
| Seatpost Size | 27.2mm |
| Headset Type | 44mm ID head tube |
| Fender Mounts | Standard |
Geometry
| Size | 48cm | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|---|
| Effective top tube length (mm) | 502 | 510 | 526 | 545 | 560 | 575 | 595 |
| Seat tube, center-center (mm) | 460 | 478 | 503 | 520 | 535 | 552 | 577 |
| Head tube length (mm) | 105 | 115 | 130 | 150 | 165 | 185 | 205 |
| Seat tube angle (deg) | 74.5 | 74 | 74 | 73.5 | 73 | 73 | 72.5 |
| Head tube angle (deg) | 70.5 | 70.5 | 70.8 | 71 | 71.2 | 71.2 | 71.5 |
| Front center (mm) | 572 | 576 | 589 | 603 | 612 | 627 | 640 |
| Chain stay length (mm) | 430 | 430 | 430 | 430 | 432 | 435 | 435 |
| BB drop (mm) | 73 | 73 | 73 | 72 | 70 | 70 | 70 |
| Reach (mm) | 353 | 353 | 365 | 374 | 379 | 389 | 398 |
| Stack (mm) | 529 | 538 | 553 | 572 | 585 | 604 | 624 |
| Standover (700x38mm tires) | 762 | 775 | 795 | 813 | 828 | 845 | 861 |
Discipline Chart
Our models span many types of riding and often have talents bridging from one area to another. Our Discipline Chart helps explain which models are best for your particular riding.
