The configurations illustrated below are intended for pricing guidance and are by no means the only way we can build your Great Divide Disc. We maintain relationships with most every component manufacturer and will custom tailor the build specification to meet your unique requirements. Please contact us to start the process.
2024 Great Divide Rim
FRAMESET STARTING AT: $5,999
The Great Divide Rim is our flagship road model. While disc brakes definitely have their advantages, there's nothing quite like the mechanical simplicity of a rim brake bike. With industry leading tire clearance thanks to our No. 6 Composites fork, you can have both the extra compliance and rolling efficiencies larger tires offer paired with the legendary road feel that only titanium can provide.
The Great Divide offers a clean, modern approach to a road rim frame with a tapered head tube designed for integrated bearings, and a rear brake hose routed through the frame to keep external cables to a minimum. Finished-off with our bespoke drop-outs, brake bridge, and Ti headset, it's a rolling showcase of titanium purity.
WHAT'S INCLUDED IN A FRAMESET?
An Great Divide Rim frameset includes the following for the list price of $5,499.:
- Great Divide Rim Frame
- No. 6 Road Rim Fork
- No. 22 Ti headset
- No. 22 Ti headset spacers
- No. 22 Ti seat post collar
- 'Raw' finish
COMPLETE BIKE PRICING
Geometry
| Size | 48cm | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|---|
| Effective top tube length (mm) | 496 | 510 | 525 | 545 | 560 | 580 | 600 |
| Seat tube, center-center (mm) | 445 | 462 | 490 | 518 | 540 | 565 | 590 |
| Head tube length (mm) | 100 | 110 | 135 | 150 | 170 | 190 | 210 |
| Seat tube angle (deg) | 75 | 74.5 | 74 | 73.5 | 73 | 73 | 72.5 |
| Head tube angle (deg) | 70.5 | 71.0 | 71.2 | 72.2 | 72.5 | 73 | 73 |
| Front center (mm) | 567 | 574 | 584 | 586 | 594 | 609 | 623 |
| Chain stay length (mm) | 412 | 412 | 412 | 415 | 415 | 415 | 418 |
| BB drop (mm) | 78 | 78 | 75 | 75 | 75 | 73 | 73 |
| Reach (mm) | 357 | 365 | 369 | 378 | 383 | 398 | 407 |
| Stack (mm) | 504 | 516 | 537 | 561 | 577 | 595 | 615 |
| Standover (700x28mm tires) | 727 | 740 | 767 | 792 | 810 | 833 | 854 |
SPECIFICATIONS
| Brake Type |
Rim brakes |
| Tire Clearance | 30mm measured tire |
| Front Axle Spacing |
100mm quick release |
| Rear Axle Spacing | 130mm quick release |
| Fork Dimensions |
48-52cm sizes: 50mm offset, 368mm length 54-60cm sizes: 45mm offset, 368mm length |
| Derailleur Hanger | Integrated to drop-out |
| Bottom Bracket Shell | T47 threaded, 68mm wide |
| Front Derailleur Clamp | 34.9mm diameter |
| Seatpost Size | 27.2mm diameter |
| Headset | Semi-internal routing | Titanium 41/47mm integrated c/w Enduro bearings |
